When both the intake as well as the exhaust valves are open, this is known as valve overlap. In layman’s terms, this allows the exhaust gas flow and the intake gas flow to influence each other.

Silky Terrier Dog Breed Playing Aro... Silky Terrier Dog Breed Playing Around

When valves overlap, what does it mean?

When the intake and exhaust valves are both open at the same time, this is known as overlap. If this occurs, it occurs at the end of the exhaust stroke and the start of the intake stroke. (Hint: You may have overlap if your intake valve opens before TDC and/or your exhaust valve closes after TDC.)

What is the advantage of having valve overlap?

Valve overlap is built into the engine and is most useful when the engine is running at higher speeds. The extra intake charge brought into the combustion chamber at higher speeds provides a significant increase in available power. Engine rpm is directly proportional to the amount of time both valves are open.

What is the purpose of engine valve overlap?

To avoid either loss of fresh charge or unscavenged exhaust gas, engine designers aim to close the exhaust valve just as the fresh charge from the intake valve reaches it. The overlap of the red and blue arcs in the diagram represents the valve overlap periods.

Why is it necessary to have an overlap?

The time when the exhaust valve is not quite closed and the intake valve is slightly open at the end of the exhaust stroke is known as valve overlap. The primary goal is for the new charge of air or air and fuel to “push out” the last of the spent fuel and air from the combustion chamber.

What is the duration of the overlap period?

The overlap period is the time in degrees when both the inlet and exhaust valves are open to help clear the combustion products from the cylinder.

Is it true that overlap reduces HC emissions?

The strategy of varying valve overlap was used to reduce methane emissions in this study. Although a torque valve cannot meet engine emission specifications, reducing the valve overlap duration while using HCNG fuel reduced hydrocarbon and methane emissions by about 41%.
